Mech-Flow Pumps manufactures precision-engineered Lobe Pumps designed for smooth, hygienic, and reliable fluid transfer. As an experienced Lobe Pumps Manufacturer in Ahmedabad and Lobe Pumps Supplier in Gujarat, we provide positive displacement pumps for food, dairy, pharmaceutical, cosmetic, beverage, and chemical industries. These pumps use synchronized rotating lobes to gently move fluids with low shear, making them ideal for high-viscosity liquids and sensitive products. Their contact-free lobe operation helps minimize wear while ensuring consistent and controlled flow.
Key Features and Benefits
Mech-Flow Pumps designs Lobe Pumps with features that support efficient and hygienic industrial operation. As a trusted Lobe Pumps Manufacturer in Ahmedabad, we focus on dependable construction, smooth fluid handling, and easy maintenance.
- Hygienic AISI 316 stainless steel construction
- Positive displacement pumping technology
- Gentle, low-shear fluid transfer
- Suitable for high-viscosity liquids
- Non-contacting lobes for reduced wear
- Precision timing gears for synchronized rotation
- Smooth and consistent flow
- Suitable for CIP cleaning applications
- Low maintenance requirements
- Customizable connection options
- Suitable for food, pharmaceutical, cosmetic, and industrial processes
Lobe Pumps Model Range
Mech-Flow Pumps offers different Lobe Pumps configurations to meet varying flow and pressure requirements. Our Lobe Pumps Supplier in Gujarat team can help select a suitable model according to fluid viscosity, required capacity, pressure, temperature, and application.
· LOBE-100
- Pressure: 7 Bar
- Port Size: 25 mm (1')
- Maximum Speed: 960 RPM
- Capacity: 50 LPM
· LOBE-150
- Pressure: 7 Bar
- Port Size: 40 mm (1½')
- Maximum Speed: 960 RPM
- Capacity: 100 LPM
· LOBE-200
- Pressure: 7 Bar
- Port Size: 50 mm (2')
- Maximum Speed: 720 RPM
- Capacity: 300 LPM
· LOBE-250
- Pressure: 6 Bar
- Port Size: 65 mm (2½')
- Maximum Speed: 720 RPM
- Capacity: 450 LPM
· LOBE-300
- Pressure: 5 Bar
- Port Size: 80 mm (3')
- Maximum Speed: 600 RPM
- Capacity: 600 LPM
· LOBE-400
- Pressure: 5 Bar
- Port Size: 100 mm (4')
- Maximum Speed: 600 RPM
- Capacity: 750 LPM
How Do Lobe Pumps Work?
The operation of Lobe Pumps is based on four basic stages. During suction, the rotating lobes create an expanding cavity that draws fluid into the pump. During the transfer stage, the fluid is trapped between the lobes and casing and carried toward the outlet. During discharge, the rotating lobes reduce the available volume and push the fluid into the delivery line. Precision timing gears maintain the required clearance between the lobes.
This controlled operation allows Lobe Pumps to move products with minimal agitation. For industries requiring hygienic and gentle pumping, Mech-Flow Pumps provides application-focused solutions as a dependable Lobe Pumps Distributor in India.
Applications of Lobe Pumps
Lobe Pumps are widely used where smooth handling of viscous, delicate, or solid-containing fluids is required. Mech-Flow Pumps supplies suitable pumping solutions for multiple processing industries as an established Lobe Pumps Manufacturer in Ahmedabad.
Common applications include:
- Dairy: Milk, cream, butter, cheese, whey and yogurt
- Bakery: Batter, dough, fillings, oils and frostings
- Beverage: Juices, concentrates, beer, wine and essences
- Food Processing: Tomato paste, mayonnaise, jams, soups and sauces
- Pharmaceutical: Syrups, creams, extracts and emulsions
- Cosmetics: Lotions, shampoos, creams and essential oils
- Meat Processing: Ground meat, emulsions and pet food
- Chemical Processing: Soaps, detergents, adhesives and viscous liquids
Looking for reliable Lobe Pumps for food, dairy, pharmaceutical, cosmetic, or industrial processing? Contact Mech-Flow Pumps today for suitable pump selection and a quotation.
Frequently Asked Questions
1. What are Lobe Pumps used for?
Lobe Pumps are commonly used for transferring high-viscosity and sensitive products in dairy, food, beverage, pharmaceutical, cosmetic, and chemical industries. They are particularly useful where gentle and hygienic fluid handling is required.
2. Do Lobe Pumps handle viscous liquids?
Yes. Lobe Pumps are positive displacement pumps and are well suited for many high-viscosity liquids. The correct pump size and operating speed should be selected according to the product characteristics and required flow rate.
3. How can I choose the right Lobe Pump?
The selection of Lobe Pumps depends on factors such as required flow, pressure, viscosity, temperature, solids content, fluid compatibility, and operating conditions. Mech-Flow Pumps can help identify a suitable configuration for your application as a Lobe Pumps Manufacturer in Ahmedabad.
